Quantabio – qPCR Instrumentation
Q uses a patented magnetic induction technology to rapidly heat samples coupled with fan forced air for cooling to acquire data in only 25 minutes. Available as a 4 channel model, the robust optical system acquires all channels simultaneously and allows for running the fastest multiplexed assays.
Q is exceptionally portable and versatile, without the need for calibration. It scales efficiently, handling up to 48 samples per run, and multiple units can connect wirelessly to a single computer via Bluetooth for processing up to 480 samples simultaneously.
Q’s distinctive spinning aluminum rotor ensures precise temperature control (± 0.05°C), outperforming traditional block-based thermal cyclers with multiple peltier heating blocks that may cause sample variations. This innovation enhances reproducibility and repeatability and enables the detection of 2-fold gene expression differences and precise identification of class IV SNP’s with 0.1°C melt temperature resolution.
Technical Specifications
| Physical | Height | 5.1 in |
| Width | 5.9 in | |
| Length | 5.9 in | |
| Weight | 4.5 lbs | |
| Thermal Performance | Temperature Accuracy | ±0.25°C |
| Temperature Uniformity | ±0.05°C | |
| Ramp Rates | Heating 4°C/s | |
| Cooling 3°C/s | Cooling 3°C/s | |
| Temperature Input Range | 40 – 99°C | |
| Reaction Tubes | Samples per Instrument | 48 |
| Reaction Volume Range | 5 – 30µL |
Additional Product Information
| Product | Kit Size | Order Code |
| Q – qPCR Instrument | Q 2-channel qPCR Instrument | Order (95900-2C) |
|---|---|---|
| Q 4-channel qPCR Instrument | Order (95900-4C) | |
| HRM License for Q qPCR Instrument | 1 HRM License | Order (95915-20) |
| Q Extended Warranty SILVER | Q Extended Warranty SILVER | Order (95900-WSIL) |
| Q Extended Warranty GOLD | Q Extended Warranty GOLD | Order (95900-WGOL) |
| Q Tubes & Caps (20 racks/box) | Q Tubes & Caps (20 racks/box) | Order (95910-20) |
Key Features
- Ultra-Fast Data Acquisition
35 cycles in 25 minutes
- Unrivaled Performance
Detect 2-fold expression level differences
- Portable & Compact
4.5 lbs – transport without ever calibrating
- Scalable & Wireless
Connect up to 10 instruments (48 samples/instrument)
- Magnetic Induction Technology
Eliminate variability vs block-based cyclers
Q is intended for molecular biology applications. This product is not intended for the diagnosis, prevention or treatment of a disease.
