Kirsch – Blood Bank Refrigerators
All KIRSCH Blood Bank Refrigerators offer you the best possible variant for the storage of your banked blood. All refrigerators are made of a robust housing, thick insulation, easy-to-maintain interior container, forced-air cooling, automatic defrosting, etc.
In order to guarantee even higher safety and quality of our appliances, Kirsch is certified according to ISO 13485. This certificate proves the conformity to the relevant specifications in the manufacture of medical products. Each BL model offers numerous KIRSCH innovations as standard equipment. Manufactured according to DIN 58371.
Key Features
- Certified high-end products
- Cooling by air circulation
Available Models
Technical Specifications
| Capacity | 95 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 160 Watts |
| Normal consumption | 0,85 KW / 24 h |
| Overall dimensions incl. distance from wall | 54 x 53,5 x 82 (w x d x h in cm) |
| Interior dimensions | 44 x 43 x 47 (w x d x h in cm) |
| Usable dimensions | 42 x 38 x 37 (w x d x h in cm) |
| Overall dimensions with door opened at 90° | 54 x 106 (w x d in cm) |
| Drawer inner dimensions | 37 x 32 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 25 kg |
| Weight | 46 kg / 50 kg (net / gross) |
Overview
- 2·drawers
- Undercounter type
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Automatic defrosting
- Melt water evaporation
- Easy accessible control panel with key switch
- Easy-to-read LED temperature display
- Optical and acoustical warning signal including power failure alarm
- Minimum/Maximum temperature memory
- Saftey control device prevents freezing
- Potential free contact and interface RS485
- Low-noise compressor
Technical Specifications
| Capacity | 170 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 155 Watts |
| Normal consumtion | 1,4 KW / 24 h |
| Overall dimensions incl. distance from wall | 70 x 77 x 122 (w x d x h in cm) |
| Interior dimensions | 55 x 52 x 60 (w x d x h in cm) |
| Usable dimensions | 53 x 41 x 47 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 70 x 136 (w x d in cm) |
| Drawer inner dimensions | 50 x 34 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 79 kg / 89 kg (net / gross) |
Overview
- 2 aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Automatic defrosting
- Melt water evaporation
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Optical and acoustical warning including power failure alarm
- Minimum/Maximum temperature memory
- Saftey control device prevents freezing
- Potential free contact and interface RS-485
Technical Specifications
| Capacity | 280 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 155 Watts |
| Normal consumption | 1,5 KW / 24 h |
| Overall dimensions incl. distance from wall | 67 x 70 x 124 (w x d x h in cm) |
| Interior dimensions | 55 x 51 x 100 (w x d x h in cm) |
| Usable dimensions | 53 x 46 x 90 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 67 x 128 (w x d in cm) |
| Drawer inner dimensions of 3 upper drawers | 49 x 39 x 10 (w x d x h in cm) |
| Drawer inner dimensions of the upper drawer below | 51 x 31 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 82 kg / 92 kg (net / gross) |
Overview
- 4·aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Automatic defrosting
- Melt water evaporation
- Drawers height-adjustable
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Minimum/Maximum temperature memory
- Optical and acoustical warning including power failure alarm
- Saftey control device prevents freezing
- Potential free contact and interface RS-485
Technical Specifications
| Capacity | 500 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 316 Watts |
| Normal consumption | 2,5 KW / 24 h |
| Overall dimensions incl. distance from wall | 77 x 76 x 193 – 196 (w x d x h in cm) |
| Interior dimensions | 62 x 56 x 140 (w x d x h in cm) |
| Usable dimensions | 60 x 45 x 127 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 77 x 144 (w x d in cm) |
| Drawer inner dimensions | 56 x 39 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 124 kg / 154 kg (net / gros) |
Overview
- 5 aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Rapid defrosting
- Melt water evaporation
- Drawers height-adjustable
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Minimum/Maximum temperature memory
- Optical and acoustical warning including power failure alarm
- Saftey control device prevents freezing
- Potential free contact and interface RS485
- Low-noise compressor
Technical Specifications
| Capacity | 700 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 316 Watts |
| Normal consumption | 2,8 KW / 24 h |
| Overall dimensions incl. distance from wall | 77 x 98 x 193 – 196 (w x d x h in cm) |
| Interior dimensions | 62 x 77 x 140 (w x d x h in cm) |
| Usable dimensions | 60 x 66 x 127 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 77 x 166 (w x d in cm) |
| Drawer inner dimensions | 56 x 60 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 163 kg / 198 kg (net / gross) |
Overview
- 5 aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Rapid defrosting
- Melt water evaporation
- Drawers height-adjustable
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Minimum/Maximum temperature memory
- Optical and acoustical warning including power failure alarm
- Saftey control device prevents freezing
- Potential free contact and interface RS-485
