Shine – Ion Chromatograph – CIC-D150

The CIC-D150 is a cost-effective, small footprint ion chromatograph which has a functionality that is currently unmatched within the UK marketplace. It has remote control function by its own designated mobile app, timing startup, preheating and key intelligence maintenance which allows it to improve productivitiy and convenience within your laboratory.

Inquiry Now

Overview

Features

Specifications

  • Leakage Alarm

If there is liquid leakage in the pipeline, the D150 liquid leakage detector will detect the liquid, and a red prompt sign will appear on the computer and the touch screen, and an alarm sound will be given to remind in time, and the pump will stop automatically after 5 minutes of no treatment.

  • Auto-range

When D150 ion chromatograph is operated, it is easy to realize the simultaneous determination of 5ppb-100ppm concentration sample without setting the range, and the signal is displayed with digital signal μs/cm.

  • Gas Liquid Separator

The bubble in the eluent will increase the baseline noise and reduce the sensitivity. A micro gas-liquid separator is set in the pipeline between the infusion pump and the eluent bottle to separate the bubble in the eluent from the eluent.

  • Timing Startup Preheating

It usually takes about 1 hour for the ion chromatograph to balance the system from start-up to sample injection analysis. When the user has prepared the eluent (or pure water for the eluent), he can set the start-up running time of the instrument in advance (the maximum setting is 24 hours), complete the start-up operation and all parameter settings.

  • Intelligent Maintenance

Set “intelligent maintenance”, the instrument can complete the flow path switch to the pure water path, the flow rate is set to 0.5ml/min, running for 1 hour.

  • Mobile APP

Mobile app is easy to operate. APP monitoring: put the device in your pocket, no matter where you are, turn on your mobile phone to view and control the field device. The mobile app can remotely control the instrument on / off and observe the operation performance parameters of the instrument.

  • Intelligent large screen

The large screen displays the operation parameters and status of the instrument, which is convenient for the operator to check the equipment status on site, and to complete the operation of instrument on-off, instrument maintenance, etc

Technical Specifications

Pump
Maximum Pressure35 MPa (PEEK)
Pressure Display Accuracy≤ 0.1 MPa
Flow Rate Range0.001 ~ 9.999 mL/min
Injector
Maximum Pressure35 MPa (PEEK)
Conductivity Detector
Cell Volume≤ 0.8 μL
Detection Range0 ~ 45000 μS/cm
Baseline Noise≤ 0.001 μS
Baseline Drift≤ 0.001 μS
Detection Resolution≤ 0.0020 nS/cm
Electronic Noise0.02 nS
Temperature RangeRoom temperature + 5 ~ 60 ℃ (41 ~ 140 ℉)
Maximum Pressure10.0 MPa
Power Requirements150 W
Dimensions (L x W x H)336 x 650 x 458 mm
Net Weight26 Kg
Gross Weight32 Kg
