PARPAS – Machining Centers – BF
The BF line features a full 5 axis milling head duly designed for profiling jobs in hard materials (steel, inconel, titanium, etc). The design of all the main machine’s components is completed using the most advanced softwares for the structure analysis (FEM), static analysis, dynamic analysis, thermal analysis and styling
BF-line concerns a vertical fixed bed type milling machine with mobile column and with one milling head with a very strong structure and because of this very proper to be presetted for a wide range of automations and suitable for heavy milling operations keeping a perfect geometrical squareness and therefore with high precision. The basic version foresees feeds through AC motors with variable Brushless type and ball recirculating screws with double pre-loaded nuts. The machine is equipped with various CNC controls based on customer’s request.
Technical Specifications
| BF-AERO | |
|---|---|
| Longitudinal axis | 2000 – 4000 mm |
| Cross axis | 800 – 1600 mm |
| Vertical axis | 800 – 1500 mm |
| Feeds | 0 ÷ 12000 mm/1` |
| Spindle | 30 – 65 Kw • 5000 – 20000 rpm |
Key Features
BF-line
The BF-line of machines has the main features in the motion of the column to perform the cross movement, the movement of the table for the longitudinal while the vertical axis is performed by the milling head carriage. This configuration enabled to achieve the best rigidity on machining combined to the best accuracy on positioning and on machining also with large loads. The assembly of a rotating and tilting head with 5 machining axis allowed to obtain a machine particularly performing and accurate in machining complex parts for the aeronautic and aerospace industry.
