Minebea Intec – X-Ray Inspection Machine
Minebea Intec offers a wide range of X-ray inspection systems for different applications.
Available in :
Minebea Intec offers a wide range of X-ray inspection systems for different applications.
Key Features
- Advanced Contaminant Detection: Utilizes sideshooter technology to identify metallic and non-metallic foreign bodies, including glass, rubber, stones, and plastics, in various containers such as PET bottles and Tetra Paks.
- Autonomous Parameter Adjustment: Automatically optimizes inspection settings to reduce false rejects, improving detection accuracy and production efficiency.
- Compact and Cost-Efficient Design: Features a monoblock generator without an external transformer, reducing technical complexity and lowering total cost of ownership.
Available Models
Dylight X-ray Inspection Machine
The Dylight X-ray inspection system is a true ‘Plug and Play’ solution, combining all functions in one compact unit. It is perfectly suited for the inspection of small
products such as snacks, energy bars and sweets.
Further Features Include
- Extremely small width of only 1 metre, allowing you to integrate the unit in your packaging line, even when only very limited floor space is available
- Complete with integrated reject mechanism and collection container for contaminated or faulty products
Dymond 40/80/120/160 X-ray Inspection System
The Dymond Series of X-ray inspection systems is extremely versatile. Featuring 4 models it is able to cover the majority of applications for inspecting packaged products. With belt widths up to 800 mm it is ideal for multi-lane applications of up to 8 traces.
Dymond S X-ray Inspection
The X-ray inspection system Dymond S combines high detection sensitivity
with low power consumption. The unit is optionally available with a so-called
chicane belt. Ideal for those situations whereonly very limited space is
available.
All Dymond S systems feature the following as standard:
- Integrated Nema 4X cooler for easy cleaning
- 500-W monoblock generator for high throughput rates and low installation and maintenance costs
- Chicane for guiding and shielding products
Dymond D X-ray Inspection
Dymond D is a dual-beam X-ray inspection system that produces two X-ray images at a 90° angle. Whether it’s tins, Tetra Paks or glass jars, multi-sided radioscopy provides maximum safety thus opening up a wealth of possibilities for manufacturers in product design.
- Maximum inspection performance with dual-beam technology: 2 × 90 kV, 9 mA
- Dymond D is equipped with a customised product feeder, chicane and shielding device
X-ray Inspection System For Bulk Materials
For all goods introduced into the production process ‘straight from the field’, Dymond Bulk offers the efficient detection and elimination of foreign bodies of all kinds.
Dymond Bulk
- Outstanding detection performance for raw materials such
Dylight X-ray Inspection Machine
X-ray Inspection Machine Belt Change
X-ray Inspection Machine Setup
Key Features
- Intuitive operator control through an icon based user interface. Products can easily be set up or adjusted without the need for special training or previous X-ray knowledge and without the involvement of a service technician.
- Outstanding detection performance while ensuring maximum line speeds
- Multi-lane solutions for up to eight lines through one detector
- Integrated network compatibility, allowing remote access by technicians for quick
- error diagnosis and support
- Powerful interfaces, including USB and Ethernet, allow an easy integration into
- data networks. Optional also via OPC-UA and SPC@Enterprise
- Hygienic design, following EHEDG principles featuring sloped surfaces and
- curved edges allowing easy inspection and cleaning, resulting in considerable
- time and cost savings
- Combining high detection sensitivity with low power consumption
- 15“ to 21” colour touchscreen display
- Covering belt widths from 200 mm up to 800 mm
- A wide range of standard possibilities for ensuring product integrity and quality, including: Checking completeness, Determining product mass, Determining compartment mass
