Lissmac – Deburring Machine – SMD 1
As cost effective basic machines they offer top machining results in surface finish and sheet metal deburring. They are characterised by low tool costs, simple handling and also by their cost effective price-performance ratio and the resulting short amortisation time.
LISSMAC SMD 1 are available as wide band grinding machines for surface machining (SMD 134 RRB) or deburring machines (SMD 124 RT). As cost effective basic machines they offer top machining results in surface finish and sheet metal deburring. They are characterised by low tool costs, simple handling and also by their cost effective price-performance ratio and the resulting short amortisation time.
Key Features
- Versatile entry-level machine
- Removal of burrs (laser/punching/plasma-cutting)
- Two roatary wheels for consistent edge rounding and uniform surface finishing
- Surface polish without complex set-up work
- Suitable for steel, stainless steel, and aluminum
- Suitable for parts with up-forms
- Touch panel for intuitive operation
- Individual aggregates can be operated independently of each other
- Stepless grinding belt speed
- Quick and easy tool change
- Space efficient footprint
Technical Specifications
| SMD 123 RE | ||
|---|---|---|
| working width max. | 950 mm (37.40 inch) | |
| material thickness max. | 1-50 mm (0.04-1.97 Inch) | |
| voltage | 400 V (50 Hz) / 480 V (60 Hz) | |
| network structure | 3~ PEN / 3~ PE+N | |
| total power | 40 A / 41 A | |
| total current consumption | 20 kW | |
| insulation class | IP 42 | |
| infinitely variable feed speed | 0.5-8 m/min (1.64-26.25 ft/min) | |
| adjustment of material thickness | electric | |
| adjustment of tools | manual | |
| weight | 1750 kg (4409 lbs) | |
| dimensions (W/D/H) | 1600/1900/1950 mm (63/75/77 inch) | |
| *You can contact us for more parameters and product information. | ||
