Lauda – Circulation Thermostats – PRO
The PRO heating circulation thermostats are designed for external applications up to 250°C. The low filling volume permits rapid heating up in the connected application. The compact construction permits space-saving installation of the thermostats. An integrated cooling coil, fitted as standard, provides cooling.
The New LAUDA PRO: Compact, Efficient, Powerful.
The PRO cooling circulation thermostats are ideal for external applications where rapid temperature changes are required. The cooling output of 0.6 and 0.8 kW, combined with a very low filling volume permit these rapid temperature changes. The thermostats have a working temperature range of -40 to 200°C. All types are fitted with a pressure-suction pump. Hybrid cooling of the refrigerating machine permits cooling using ambient air or, in addition, using cooling water.
Available Models
Technical Specifications
| Working temperature min. | 80°C |
| Working temperature max. | 250°C |
|---|---|
| Interface | Ethernet, USB (Type B) |
| Temperature stability | 0.05 ±K |
| Bath volume max. | 4.4 L |
| Heater power | 2.5 kW |
Technical Specifications
| Working temperature min. | -40°C |
| Working temperature max. | 200°C |
|---|---|
| Interface | Ethernet, USB (Type B) |
| Temperature stability | 0.05 ±K |
| Bath volume max. | 4.4 L |
| Heater power | 2.5 kW |
Technical Specifications
| Working temperature min. | -45°C |
| Working temperature max. | 200°C |
|---|---|
| Interface | Ethernet, USB (Type B) |
| Temperature stability | 0.05 ±K |
| Bath volume max. | 4.4 L |
| Heater power | 2.5 kW |
Technical Specifications
| Working temperature min. | -50°C |
| Working temperature max. | 200°C |
|---|---|
| Interface | Ethernet, USB (Type B) |
| Temperature stability | 0.05 ±K |
| Bath volume max. | 4.4 L |
| Heater power | 2.5 kW |
Technical Specifications
| Working temperature min. | -90°C |
| Working temperature max. | 200°C |
|---|---|
| Interface | Ethernet, USB (Type B) |
| Temperature stability | 0.05 ±K |
| Bath volume max. | 4.4 L |
| Heater power | 2.5 kW |
Key Features
100% flexibility for internal temperature control
- Functional check of electronic components
- Material testing of metal and plastic samples
- Sensor calibration
- Temperature control of measuring cells
100% efficiency for external applications
- Thermal control of chemical and biological reactions
- Precise temperature control for crystallization processes
- Temperature control of measuring and testing rigs, heat exchangers and distillation plant
