Hobart – Warewashing – Utensil Washer
Warewashing – Conveyor Dishwasher
Available Models
Technical Specifications
| Cycle times in sec. [1] | 90 / 180 / 360 and special cycles |
| Water consumption | 2.0 l/rack |
|---|---|
| Tank capacity | 10.6 l |
| Tank heating | 0.8 kW |
| Wash pump | 0.6 kW / 350 l/min |
| Rack size | 500 x 500 mm |
| Loading height | 425 mm |
| Noise level | 60.5 dB (A) |
| Weight (gross / net) | 70 / 60 kg |
| Max. supply water temperature | 60°C |
| Required flow rate | 5 l/min |
| Power cord | 2,000 mm |
Key Features
- VISIOTRONIC Intelligent Control: ensures a simple and intuitive operating with a single button. When the display is activated by a proximity sensor, all the necessary information appears in the large display, in clear text or in the form of symbols
- Intelligent wash water control: constantly measures the quality of the wash water and keeps the amount of rinsing needed in each rinse cycle to the minimum in order to guarantee a fully hygienic wash result. This reduces the amount of fresh water used per rinse cycle up to 2.0 l
- Double rack system: two racks can be washed in a single wash cycle. One rack of cups can be washed underneath, while a second rack containing dishes and cutlery can also be washed above it. Thanks to the optimum use of the entire wash chamber the performance of the machine can be doubled
- CLIP-IN Wash and Rinse Arms both the wash and rinse arms can be lifted out of the wash chamber and replaced with one hand and without any tools
- Intelligent data documentation: automatic recording of important operational data and consumptions and indication on the display
Technical Specifications
| flexible drain hose 2000 mm | 24 mm inner / 28 mm outer diam. |
| power cord | 1800 mm |
|---|---|
| 2 chemical suction hoses | 2500mm each |
| hose for rinse aid | 2500 mm |
| rinse water consumption | 8 l/cycle |
| tank capacity | 80 l |
| tank heating | 3.3 kW |
| voltage | 400 / 50 / 3 / N |
| booster loading | 15 kW |
| pump capacity | 2.7 kW / 1150 l/min |
| noise level | 65 dB(A) |
| weight gross / net | 236 / 221 kg |
Key Features
- Significantly less manual pre-cleaning and second runs by intensive wash cycles withsteam injection and direct injection of detergent
- Extra capacity by side wash system: e.g. up to 6 GN-trays 1/1, 4 EN2 container
- Double walled housing for low noise level and energy efficiency
- Strainer Control PROOF: prevents operation without tank strainer
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- The optional exhaust heat recovery with integrated Door System VAPOSTOP uses steam to heat fresh feed water and reduces the amount of power needed to reach the final rinse temperature, saving up to 1.5 kW/h.
- Door System VAPOSTOP prevents vapour to escape from machine when door is opened
Technical Specifications
| flexible drain hose 2000 mm | 24 mm inner / 28 mm outer diam. |
| power cord | 1800 mm |
|---|---|
| 2 chemical suction hoses | 2500 mm each |
| hose for rinse aid | 2500 mm |
| rinse water consumption | 14 l/cycle |
| tank capacity | 130 l |
| tank heating | 6 kW |
| voltage | 400 / 50 / 3 / N |
| booster loading | 18 kW |
| total loading | 24.2 kW |
| pump capacity | 2 x 2.7 kW / 2 x 1150 l/min |
| noise level | 67 dB(A) |
| weight gross / net | 391 / 371 kg |
Key Features
- Significantly less manual pre-cleaning and second runs by intensive wash cycles with steam injection and direct injection of detergent
- Extra capacity by side wash system: e.g. up to 8 GN-trays 1/1, 5 EN2 container
- Double walled housing for low noise level and energy efficiency
- Strainer Control PROOF: prevents operation without tank strainer
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- The optional exhaust heat recovery with integrated Door System VAPOSTOP uses steam to heat fresh feed water and reduces the amount of power needed to reach the final rinse temperature, saving up to 5.2 kW/h.
- Door System VAPOSTOP prevents vapour to escape from machine when door is opened
Technical Specifications
| flexible drain hose 2,000 mm | 24 mm inner / 28 mm outer diam. |
| power cord | 1,800 mm |
|---|---|
| 2 chemical suction hoses | 2,500 mm each |
| water consumption | 4.5 l / rack |
| tank capacity | 80 l |
| tank heating | 3.3 kW |
| power supply | 400 / 50 / 3 / N |
| booster loading | 12.3 (6.1) kW |
| total loading | 15.4 (12.6) kW |
| pump capacity | 2.7 kW | 1,300 l / min. |
| noise level | 65 dB (A) |
| weight gross / net | 230 / 215 kg |
Key Features
- Washing POWER-PLUS: high pressure washing to wash heavily soiled wash items
- Strainer Control PROOF: prevents operation without tank strainer
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- Loading height L: above-average loading height of 860 mm
- Machine height 2-in-1: machine height can be reduced by up to 200 mm with the door open – for use in spaced with low ceilings
- The optional waste water heat recovery system transfers heat from hot waste water to the fresh-water supply, reducing boiler power consumption and saving up to 5.2 kW/h.
Technical Specifications
| flexible drain hose 2,000 mm | 24 mm inner / 28 mm outer diam. |
| power cord | 1,800 mm |
|---|---|
| 2 chemical suction hoses | 2,500 mm each |
| water consumption | 7.5/9/9 l / rack |
| tank capacity | 130 l |
| tank heating | 6 kW |
| voltage | 400 / 50 / 3 / N |
| booster loading | 15 (9) kW |
| total loading | 21.2 (15.7) kW |
| pump capacity | 2.7 kW | 1,300 l / min. |
| noise level | 67 dB (A) |
| weight gross / net | 332 / 312 kg |
Key Features
- Washing POWER-PLUS: high pressure washing to wash heavily soiled wash items
- Strainer Control PROOF: prevents operation without tank strainer
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- Loading height L: above-average loading height of 865 mm
- Machine height 2-in-1: machine height can be reduced by up to 200 mm with the door open – for use in spaces with low ceilings
- The optional waste water heat recovery system transfers heat from hot waste water to the fresh-water supply, reducing boiler power consumption and saving up to 8.6 kW/h.
- The optional exhaust heat recovery including an integrated Door System VAPOSTOP uses steam to heat fresh feed water and reduces the amount of power needed to reach the final rinse temperature by up to 3.5 kW/h
Technical Specifications
| flexible drain hose 2,000 mm | 24 mm inner / 28 mm outer diam. |
| power cord | 1,800 mm |
|---|---|
| 2 chemical suction hoses | 2,500 mm each |
| water consumption | 7.5/9/9 l / rack |
| tank capacity | 130 l |
| tank heating | 6 kW |
| voltage | 400 / 50 / 3 / N |
| booster loading | 15 (7.5) kW |
| total loading | 21 (15.7) kW |
| pump capacity | 2.7 kW | 1,300 l / min. |
| noise level | 68 dB (A) |
| weight gross / net | 399 / 379 kg |
Key Features
- Washing POWER-PLUS: high pressure washing to wash heavily soiled wash items
- Strainer Control PROOF: prevents operation without tank strainer
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- The optional waste water heat recovery system transfers heat from hot waste water to the fresh-water supply, reducing boiler power consumption and saving up to 8.6 kW/h.
- Single-button Control SMARTRONIC: colour-coded status indication and remaining time indicator
- Refill signal for machines with external chemical container
Technical Specifications
| flexible drain hose 2,000 mm | 24 mm inner / 28 mm outer diam. |
| power cord | 1,800 mm |
|---|---|
| 2 chemical suction hoses | 2,500 mm each |
| water consumption | 7.5/9/9 l / rack |
| tank capacity | 130 l |
| tank heating | 6 kW |
| voltage | 400 / 50 / 3 / N |
| booster loading | 15 (7.5) kW |
| total loading | 21 (15.7) kW |
| pump capacity | 2 x 2.7 kW | 2 x 1,300 l / min. |
| noise level | 68 dB (A) |
| weight gross / net | 452 / 432 kg |
Key Features
- Washing POWER-PLUS: high pressure washing to wash heavily soiled wash items
- Strainer Control PROOF: prevents operation without tank strainer
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- Loading height L: above-average loading height of 880 mm (with rack 850 mm)
- The optional drain heat recovery system transfers heat from hot waste water to the fresh-water supply, reducing boiler power consumption and saving up to 8.6 kW/h
- Single-button Control SMARTRONIC: colour-coded status indication and remaining time indicator
- Refill signal for machines with external chemical container
- HYGIENE Machine Care Programme and Chemical Tablets INTENSIVE: remove calcium carbonate and other deposits from tank wall
Key Features
- Tabling programme for highest demands
- Integrated sloped drain towards machine
- integrated splash protection panel over whole length
- Splash protection panels closed on both sides
- Sink drain in general at rear towards machine
- Special lengths available
- Stable square profile legs and cross bars
- Solid stainless steel construction
Brand
HOBART manufactures products for the food service and food retail industry, including cooking, food preparation, warewashers and waste handling, weight wrap, Baxter baking and Traulsen refrigeration.
HOBART Thailand and Indochina office has been established with Warehouse and the Spare Parts Center in objectives to support distribution network throughout the region of Thailand and CLMV Countries which consist of Cambodia, Laos, Myanmar and Vietnam upon economic expansion and commit in quality genuine profession as stated HOBART proudly supporter you always.
