Hobart – Warewashing – Hood Type Dishwasher
Warewashing – Hood Type Dishwasher
Available Models
Technical Specifications
| Power cord | 2,500 mm |
| Hoses for detergent and rinse agent | 2,000 mm each |
|---|---|
| Water consumption | 2.5 l / rack |
| Tank capacity | 21 l |
| Tank heating | 2.5 kW interlocked |
| Power supply | 400 / 50 / 3 / N |
| Booster loading | 12.6 kW |
| Total loading | 7 kW / 3 x 16 A |
| Pump capacity | 0.7 kW / 350 l/min |
| Loading height | 440 mm |
| Noise level | 67 dB(A) |
| Weight gross / net | 121 / 101 kg |
Key Features
- Ready to install: incl. fill and drain hoses, power cord, non-return valve
- Completely equipped with rinse pressure pump
- Electronic Control SMARTRONIC: with status indication
- Hood Design EASY-LIFT: 50% less effort is needed to open the hood – a real benefit for the operator
- Hood Concept E-STORE with fully enclosed 4-sided hood keeps the steam and also the energy inside the system: energy saving up to 3 kW/h. Less humidity in the kitchen area and better hygienic conditions
- Rinse Pump ACCURINSE: guarantees a constant 2,5 l rinse, independent of on-site pressure. Saves up to 30% water, energy and chemicals.
- Wide Angle Nozzles FAN are precise and efficient: wash water is distributed evenly around the wash chamber
Technical Specifications
| Power cord | 2,500 mm |
| Hoses for detergent and rinse agent | 2,000 mm each |
|---|---|
| Water consumption | 2,5 l / rack |
| Tank capacity | 22 l |
| Tank heating | 3 kW interlocked |
| Power supply | 380-415V/ 50H / 3 / N |
| Booster loading | |
| Water inlet 10°C ¹ | 12.6 kW |
| Water inlet 60°C² | 6.3kW |
| Total loading | 16 kW¹ | 9.7KW² |
| Pump capacity | 0,73 kW |
| Loading height | 440 mm |
| Noise level | 67 dB(A) |
| Net weight of machine | 120 kg |
Key Features
- Ready to install: incl. fill and drain hoses, power cord, non-return valve
- Completely equipped with rinse pressure pump
- Electronic Control SMARTRONIC: with status indication
- Hood Design EASY-LIFT: 50% less effort is needed to open the hood – a real benefit for the operator
- Hood Concept E-STORE with fully enclosed 4-sided hood keeps the steam and also the energy inside the system: energy saving up to 3 kW/h. Less humidity in the kitchen area and better hygienic conditions
- Rinse Pump ACCURINSE: guarantees a constant 2,5 l rinse, independent of on-site pressure. Saves up to 30% water, energy and chemicals.
- Wide Angle Nozzles FAN are precise and efficient: wash water is distributed evenly around the wash chamber
Technical Specifications
| Flexible drain hose 2,000 mm | 20mm inner / 25mm outer diam. |
| Power cord | 2,500 mm |
|---|---|
| Hoses for detergent and rinse agent | 2,000 mm each |
| Water consumption | 2.5 l / rack |
| Tank capacity | 21 l |
| Tank heating | 2.5 kW interlocked |
| Power supply | 400 / 50 / 3 / N |
| Booster loading | 6.15 kW |
| Total loading | 7 kW / 3 x 16 A |
| Pump capacity | 0.7 kW / 350 l/min |
| Loading height | 440 mm |
| Noise level | 67 dB(A) |
| Weight gross / net | 121 / 101 kg |
Key Features
- Ready to install: incl. fill and drain hoses, power cord, non-return valve
- Completely equipped with rinse pressure pump, drain pump and chemical dispenser
- Fine Filter System GENIUS-X2: advanced filter system with pre-wash function reduces detergent consumption by up to 30%
- Single-button Control SMARTRONIC: with colour-coded status indication and remaining cycle time
- Hood Design EASY-LIFT: 50% less effort is needed to open the hood ย– a real benefit for the operator
- Hood Concept E-STORE with fully enclosed 4-sided hood keeps the steam and also the energy inside the system: energy saving up to 3 kW/h. Less humidity in the kitchen area and better hygienic conditions
- Insulated hood reduces noise and heat loss by up to 50% (optional)
- Rinse System ACCURINSE: guarantees a constant 2.5 l rinse, independent of on-site pressure. Saves up to 30% water, energy and chemicals.
- Wide Angle Nozzles FAN are precise and efficient: wash water is distributed evenly around the wash chamber
- HYGIENE Machine Care Programme and Chemical Tablets INTENSIVE: remove calcium carbonate and other deposits from tank wall
- Water Softening System NON-STOP (optional): regenerates simultaneously to the wash cycle without interrupting the cycle duration
- Heat Recovery E-SAVE (optional) transfers waste energy from the hot drain water into the cold fresh-water via an integral heat exchanger. Saves up to 6.5 kW
- Hood System VAPOSTOP (optional): prevents vapour from escaping from the machine when the door is opened (only for AMX(R)-16 and AMX(R)S-16)
Technical Specifications
| Flexible drain hose 2,000 mm | 20mm inner / 25mm outer diam. |
| Power cord | 2,500 mm |
|---|---|
| Hoses for detergent and rinse agent | 2,000 mm each |
| Water consumption | 5 l / cycle |
| Tank capacity | 42 l |
| Tank heating | 2 x 2.5 kW |
| Power supply | 400 / 50 / 3 / N |
| Booster loading | 12.3 (6.15) kW |
| Total loading | 18.8 kW / 3 x 35 A |
| Pump capacity | 2 x 0.7 kW / 350 l/min |
| Loading height | 440 mm |
| Noise level | 68 dB (A) |
| Weight gross / net | 212 / 180 kg |
Key Features
- Double wide wash chamber can cover even bigger containers, etc.
- Ready to install: incl. fill and drain hoses, power cord, non-return valve
- Completely equipped with rinse pressure pump, drain pump and chemical dispenser
- Fine Filter System GENIUS-X²: advanced filter system with pre-wash function reduces detergent consumption by up to 30%
- Single-button Control SMARTRONIC: with colour-coded status indication and remaining cycle time
- Hood Design EASY-LIFT: 50% less effort is needed to open the hood – a real benefit for the operator
- Hood Concept E-STORE with fully enclosed 4-sided hood keeps the steam and also the energy inside the system: energy saving up to 3 kW/h. Less humidity in the kitchen area and better hygienic conditions
- Insulated hood reduces noise and heat loss up to 50%
- Rinse System ACCURINSE: guarantees a constant 5 l rinse, independent of on-site pressure. Saves up to 30% water, energy and chemicals.
- Wide Angle Nozzles FAN are precise and efficient: wash water is distributed evenly around the wash chamber
- HYGIENE Machine Care Programme and Chemical Tablets INTENSIVE: remove calcium carbonate and other deposits from tank wall
- Water Softening System NON-STOP (optional): regenerates simultaneously to the wash cycle without interrupting the cycle duration
- Heat Recovery E-SAVE (optional) transfers waste energy from the hot drain water into the cold fresh-water via an integral heat exchanger. Saves up to 13 kW
Technical Specifications
| Flexible drain hose 2,000 mm | 20mm inner / 25mm outer diam. |
| Power cord | 2,500 mm |
|---|---|
| Hoses for detergent and rinse agent | 2,000 mm each |
| Water consumption | 1.6 l / rack |
| Tank capacity | 40 l |
| Tank heating | 2.5 kW |
| Power supply | 400 / 50 / 3 / N |
| Booster loading | 12.3 (6.15) kW |
| Total loading | 17.1 kW / 3 x 35 A |
| Pump capacity | 2 x 1.1 kW |
| Loading height | 440 mm |
| Noise level | 70 dB (A) |
| Weight gross / net | 148 / 128 kg |
Key Features
- Vapo Rinse ECO: switchable steam rinse cycle reduces fresh-water consumption to 1.6 l/cycle
- Washing HOT-TEMP: higher temperature of 63°C increases the capacity up to 75 racks/h
- Cutlery cycle: removes even persistent residues by the use of steam
- Insulated hood reduces noise and heat loss up to 50%
- Cleaning Cycle STARCH REMOVAL removes the starch from the crockery
- Wash System ROTOR-X: separate rotating upper and lower 4 spoke wash arms deliver dynamic wash power
- Wash programme POWER-PLUS: selectable higher pressure programme to wash heavily soiled wash items
- Fine Filter System GENIUS-X²: advanced filter system with pre-wash function reduces detergent consumption by up to 30%
- Ready to install: incl. fill and drain hoses, power cord, non-return valve
- Completely equipped with rinse pressure pump, drain pump and chemical dispenser
- Single-button Control SMARTRONIC: with colour-coded status indication of remaining cycle time
- Hood Design EASY-LIFT: 50% less effort is needed to open the hood – a real benefit for the operator
- Hood Concept E-STORE with fully enclosed 4-sided hood keeps the steam and also the energy inside the system: energy saving up to 3 kW/h. Less humidity in the kitchen area and better hygienic conditions
- Rinse Pump ACCURINSE: guarantees a constant 1.6/2.3 l rinse, independent of on-site pressure. Saves up to 30% water, energy and chemicals
- Wide Angle Nozzles FAN are precise and efficient: wash water is distributed evenly around the wash chamber
- HYGIENE Machine Care Programme and Chemical Tablets INTENSIVE: remove calcium carbonate and other deposits from tank wall
- Water Softening System NON-STOP (optional): regenerates simultaneously to the wash cycle without interrupting the cycle duration
- Heat Recovery E-SAVE (optional) transfers waste energy from the hot drain water into the cold fresh-water via an integral heat exchanger. Saves up to 6.5 kW
Technical Specifications
| Flexible drain hose 2,000 mm | 20mm inner / 25mm outer diam. |
| Power cord | 2,500 mm |
|---|---|
| water consumption | 2,5 l |
| tank capacity | 21 l |
| tank heating | 2,5 kW interlocked |
| Voltages + Total loading | 440/60/3/PE – 10,2 kW | 230/60/3/PE – 9,2 kW | 400/50/3/PE – 9,2 kW |
| pump capacity | 0,7 kW / 370 l/min |
| noise level | 67 dB(A) | 65 dB(A) insul. |
| weight net | appr. 105 kg |
Key Features
- Built acc. USPHS/NSF regulations
- Ready to install: incl. fill and drain hoses, power cord, class “A”airgap
- Completely equipped with rinse pressure pump and drain pump
- Fine Filter System GENIUS-X2: advanced filter system with prewash function, reduces detergent consumption by up to 30 %.
- Electronic Control SMARTRONIC: with color-coded status indication
- Hood Design EASY-LIFT: 50 % less effort is needed to open the hood ย– a real benefit for the operator
- Hood Concept E-STORE with fully enclosed 4-sided hood keeps the steam and also the energy inside the system: energy saving up to 3 kW. Less humidity in the kitchen area and better hygienic conditions
- Insulated hood reduces noise and heat loss up to 50 %
- Rinse Pump ACCURINSE: guarantees a constant 2.5l rinse, independent of on-site pressure. Saves up to 30% water, energy and chemicals.
- Wide Angle Nozzles FAN are precise and efficient: wash water is distributed evenly around the wash chamber
- Water Softener NONSTOP (optional): regenerates simultaneously to the wash cycle without interrupting the cycle duration
- Heat Recovery E-SAVE (optional) transfers waste energy from the hot drain water into the cold fresh water via an integral heat exchanger. Saves up to 6,5 kW
- Stainless steel back panel
- Marine stainless steel feet
- Different marine voltages available
