HAIMER – Presetting Technology – UNO Series
HAIMER Microset tool presetting technology complements the existing HAIMER portfolio of an extensive tool holding program, shrinking and balancing technology, tool management logistics as well as 3D measuring devices and solid carbide cutting tools. As a result, we can offer you a perfectly matching product range from a single source.
In addition to precision, speed and reliability, the UNO series also includes numerous features in terms of its equipment. The new design and improved ergonomics set new standards. High quality components are used, e.g. from SMC, Bosch, Heidenhain, IDS.
Available Models
Technical Specifications
| Maximum tool diameter | 400 mm. |
| Maximum tool weight | 30 Kg. |
| Weight | 95 Kg. (20|40) / 105 Kg. (20|70) |
Technical Specifications
| Maximum tool diameter | 400 mm. |
| Maximum snap gauge tool diameter | 100 mm. |
| Maximum tool weight | 30 Kg. |
| Weight | 140 Kg. (20|40) / 155 Kg. (20|70)Kg. |
Technical Specifications
| Maximum tool diameter | 400 mm. |
| Maximum snap gauge tool diameter | 100 mm. |
| Maximum tool weight | 30 Kg. |
| Weight | 240 Kg. (20|40) / 255 Kg. (20|70) |
Technical Specifications
| Maximum tool diameter | 400 mm. |
| Maximum snap gauge tool diameter | 100 mm. |
| Maximum tool weight | 30 Kg. |
| Weight | 240 Kg. (20|40) / 255 Kg. (20|70) |
Key Features
HAIMER Presetting Technology | UNO smart
- Robust, durable gray cast iron construction.
- Thermo-optimized material combination for better repeatability.
- Manual operation.
- Repeatability ± 5 μm.
HAIMER Presetting Technology | UNO premium
- Robust, durable gray cast iron construction.
- Thermo-optimized material combination for better repeatability.
- Manual operation.
- Repeatability ± 2 μm.
HAIMER Presetting Technology | UNO autofocus
- Robust, durable gray cast iron construction.
- Motorized fine adjustment of the C-axis.
- Release-by-Touch.
- Repeatability ± 2 μm.
HAIMER Presetting Technology | UNO automatic drive
- Automatic tool measurement in 3 axes.
- Motorized fine adjustment.
- Release-by-Touch.
- Repeatability ± 2 μm.
HAIMER Microset Presetting Technology Video
The efficient tool presetting equipment from HAIMER Microset optimises your machining processes from the ground up. Improve your tool life, generate better surface finishes and boost overall process reliability in your production.
Key Industries
- Aerospace
- Automotive
- Die & Mould
- Education & Academics
- Electronics
- Machinery & Manufacturing
- Medical
- Mining & Minerals
- Oil & Gas
- Semiconductor, Solar & Electronics
- Shipbuilding
Brand
HAIMER is a family run, medium size company located in Igenhausen, Bavaria near Augsburg, Germany. We design, produce and sell innovative, high precision products for metal cutting as well as for other branches including automotive, aerospace, energy, rail and general machining. In addition to our large offering of tool holders in all popular interfaces and lengths, including our shrinking and balancing machines, as well as our 3-D Sensors, solid carbide cutting tools, our product offering now also includes tool presetting machines.
