Felsomat – Automation Storage Systems – FSC600
The Felsomat stacker cell with its unique functional design offers possibilities for the material flow of manufacturing lines which are rarely realized with other decoupling modules. The palletizer unit works in two stacking directions, and it is therefore possible to introduce and retrieve stacks at the same position making a central interface for the operator and eliminates unnecessary space required for loading the cell at multiple points. When the central loading door is open, a stack with finished components can be retrieved and a new stack with rough parts introduced into the loading bay of the cell. The stack change is confirmed at the control panel.
Product Description
The compact and modular stacker cell reduces the required floor space and gives maximum operation flexibility. The cell can be enhanced at any time in height, length and functionality and can be adapted for individual production requirements.
The organization of the material flow is quite simple. In the FSC the work pieces are supplied in a defined order in wire baskets on a trolley where they can be picked up by a gantry or robot. The baskets are handled with an integrated pick and place unit with a horizontal and vertical NC-axix. The cell operates autonomously and the fininished part / raw part exchange function can be performed without interruption of the machine loading sequence due to an integrated safety guard.
Technical Specifications
| robot | 30Kg payload, the scope of work according to customer site conditions | |
| the maximum workpiece diameterø | 300mm | |
|---|---|---|
| maximum workpiece height | 50mm | |
| maximum workpiece weight | 10kg | |
| pallet size | separate design according to the workpiece | |
| number of loads | depending on the number of pallets and the length of the bin | |
| *You can contact us for more parameters and product information. | ||
Key Features
Automation Storage Systems FSC600
- Compact design with small foot pring
- Scalable cell unit in width and length
- Work piece supply with an autonomous cell, freely configurable in relation to the position of the machine tool
- High inventory of parts per stack
- Loading of the baskets only once, there is no manual part handling required afterwards for downstream operations.
- No idle times at basket or stack exchange
- No need for a constant attentions by the operator at the cell
