CytoSMART – Compact Inverted Lab Microscope – Lux2
The CytoSMART Lux2 provides an easy and cost-effective solution for time-lapse imaging. Monitor cell proliferation, motility and morphology for hours up to weeks at a time.
The CytoSMART Lux2 is a compact inverted lab microscope for bright-field live cell imaging. It works from inside any standard CO2-incubator and can be used in routine cell culture processes.
Technical Specifications
Unit dimensions (L x W x H) | 133 x 90 x 100 mm |
Weight | 0.5 kg (1.1 lb) |
---|---|
Optics | Brightfield with digital phase contrast |
Magnification | 10x fixed objective, digital zoom to 20x |
Light source | LED |
Camera | 5MP CMOS |
Image size | 960 x 960 pixels |
Field of view | 1.84 x 1.84 mm |
Culture vessels | Flasks, well plates, petri dishes, slides |
Storage | 50 GB cloud storage (Microsoft Azure cloud) |
Operating conditions | 5-40 °C, 20-95% humidity |
Warranty | 1 year parts & labor |
Support | Via mail and live chat |
Key Features
Lux2 Compact Inverted Lab Microscope
- World’s smallest live-cell imager
Live-cell imaging has become a desired analytical tool in many cell biology laboratories focusing on e.g. pharmacological research, regenerative medicine and tissue engineering. Livecell imaging is generally a difficult task, because it requires large, costly, high-end devices that are difficult to operate. The CytoSMARTâ„¢ Lux2 is a compact inverted microscope for brightfield live-cell imaging that makes live-cell imaging easy and affordable so it can be used by every biological laboratory. Even in routine cell culture processes.
- No issues with environmental controls
Tight control of the environment (e.g. temperature, CO2) is one of the most critical factors determining the success or failure of a live-cell imaging experiment. When using a conventional microscope equipped with an incubator box, it can be quite a challenge to maintain the cells in a healthy state and functioning normally while being imaged for a longer period of time.
The CytoSMARTâ„¢ Lux2 operates at lowvoltage and is designed for safe use in a regular CO2-incubator. This enables you to minimize environmental changes, giving you more reliable and repeatable experiments for less work.
- Easy data storage and image analysis
The CytoSMARTâ„¢ Lux2 can be set to record images at specific intervals (between 5-60 minutes) for minutes, hours and days. In fact, it is one of the few systems that can run for weeks. The recorded images are sent to the CytoSMARTâ„¢ Cloud where they are analyzed using our custom, cloud-based, image analysis software. You can select the appropriate image analysis algorithm, such as confluence detection, according to the experiment you are performing. The image analysis data is represented in the images as well as graphically in a dashboard.
- Easy access. Anywhere. Anytime.
Thanks to cloud data storage and cloudbased image analysis, you can access your recording and view the cell culture in almost real-time from anywhere on any pc, laptop, tablet or mobile phone with internet access. All the recorded data such as images (.jpg), time-lapse video (.avi) or confluency data (.csv) can be downloaded for further processing. In case you have set a notification, our email alerts will keep you up-to-date on confluence levels or long-term temperature drops.
How to Use the CytoSMART Lux2 Live-cell Imager
Cell Culture Monitoring Using the Cytosmart Lux2
Key Industries
- Biopharmaceutical and Biotechnology
