BioMérieux – Food Pathogen Detection – Real-time PCR Gene-up

With Gene-up, you’re not just getting an intuitive, real-time PCR solution for pathogen detection. You’re also getting 50 years’ of microbiology leadership from a vigilant team that embraces the highest standards in microbiology safety.

Simplifying workflows with our easy-to-use automated food pathogen detection system can improve overall lab productivity. With Gene-up, limited training is required, cross-contamination risks are decreased, and rapid results speed up the decision process — improving overall manufacturing efficiency.

• Rapid – speed up operations with quick pathogen detection
• Simple and intuitive to set up and run
• Reliable – for consistently high-quality results
• Flexible and adaptable

Gene-up solutions offer ready-to-use test kits for your most pressing food safety concerns. The simple workflow is consistent for each test, minimizing training and improving efficiencies.

Technical Specifications

The GENE-UP instrument can be positioned on any stable and non-moving bench. A typical installation requires workspace of: width 40” and a bench depth 24” and a clearance height of 36”.

GENE-UP Instrument
Dimensions	20.87 x 9.84 x 15.75 inches
Weight (lbs.)	37.42
Electrical Requirements
Power	6.5 amps @ 120 VAC
Heat Dissipated	2218 BTU/hr
Voltage	120 Volts
Electrical Consumption	20 amps
Frequency	60 Hz
Environmental Conditions
Temperature Range	59°F to 86°F with no wide temperature fluctuations
Room Relative Humidity	10% to 8-% RH, non-condensing
Altitude	-328 to 9842 feet above sea level

Peripherals
Computer	1.7 amps @120 VAC
Monitor	0.3 amps @120 VAC
Printer	5.0 amps @120 VAC

Key Features

Real-Time PCR Gene-up

• 5-minute mechanical Generic lysis
• Real-time PCR analysis coupled with end-point melt peak analysis
• Same PCR run for all parameters
• AOAC & AFNOR validated kits
• Room temperature storage
• Single enrichment
• Optimized productivity with Magic Cap®
• Run in less than 1 hour
• Standardized protocol and workflow
• VILINK® remote diagnostics & resolution

GENE-UP® – System for Foodborne Pathogen Testing
