  • Brochure: Dynamic climate chambers: MK / MKF / MKT / MKFT series


  • Factsheet: Model MK 56


The BINDER MK series chamber is suitable for all heat and cold tests between -40 °C and 180 °C. The MK is a clever alternative to complex individual solutions for cyclical temperature tests.

key Features

  • Homogeneous climate conditions thanks to APT.lineâ„¢ technology
  • Comprehensive programming and data acquisition
  • Large heated viewing window

Environmental Simulation Chambers for Rapid Temperature Changes

BINDER environmental simulation chambers in the MK series are the number one choice for dynamic temperature profiles. Heat and cold tests alike can be performed with precision within these climate chambers. Designed for rapid temperature changes, the environmental simulation chambers can be used within a temperature range of between -40 °C and +180 °C. The patented APT.line™ air flow concept guarantees accurate measured values at every temperature setting – across the entire usable space and even when the climate chambers are fully loaded.

BINDER environmental simulation chambers in the MK series feature programmable condensation protection for samples. Equipped with a heated viewing window with LED interior lighting, these chambers can be adjusted to suit any requirements with ease using the controller with interval programming. The large access area even makes equipping the chambers nice and convenient.



BINDER Environmental Simulation Chambers for Flexibility and Precision

The BINDER APT-COMâ„¢ 3 Basic Edition communication software and a troubleshooting system with visual and acoustic alarms are also included. These environmental simulation chambers offer maximum flexibility in practice thanks to their stable casters with locking brakes, which enable them to be transported from A to B in no time and then securely locked in position, with the water supply independent of location.

Dynamic climate chambers from BINDER are suitable for a wide range of applications, including material testing, aging and stress tests, and environmental simulation. Whatever they are tasked with, these units impress with their precision and performance, delivering reliable, norm-compliant test results and providing you with the basis for working with accuracy and success. The opportunities available with these environmental simulation chambers extend well beyond those offered by a standard heating chamber.

Technical Specifications

ModelMK 56MK 115MK 240MK 720
Housing dimensions not incl. fittings and connections (W x H x D)720 x 1445 x 778 mm980 x 1725 x 865 mm1115 x 1710 x 925 mm1580 x 2005 x 1140 mm
Internal dimension (W x H x D)400 x 420 x 350 mm600 x 480 x 400 mm735 x 700 x 443 mm1200 x 1020 x 600 mm
Net weight168 kg260 kg340 kg570 kg
Interior volume60 L115 L228 L734 L

Available Models

  • Temperature range: -40 °C to 180 °C
  • APT.lineâ„¢ preheating chamber technology
  • Programmable condensation protection for test material
  • Heated viewing window with LED interior lighting
  • BINDER Multi Management Software APT-COMâ„¢ Basic Edition
  • Troubleshooting system with visual and audible alarms
  • Intuitive touchscreen controller with time-segment and real-time programming
  • Internal data logger, measured values can be read out in open format via USB
  • Unit self-test for comprehensive status analysis
  • Access port with silicone plug, 50 mm, left
  • Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
  • 4 castors, two with brakes
  • Computer interface: Ethernet
  • Adjustable ramp function
  • Integrated chart recorder
  • Real-time clock
  • 1 stainless steel rack
  • Inner chamber made of stainless steel
  • CFC-free refrigerant R-452A
  • Cooling with compressor cooling unit
  • Temperature range: -40 °C to 180 °C
  • APT.lineâ„¢ preheating chamber technology
  • Programmable condensation protection for test material
  • Heated viewing window with LED interior lighting
  • BINDER Multi Management Software APT-COMâ„¢ Basic Edition
  • Troubleshooting system with visual and audible alarms
  • Intuitive touchscreen controller with time-segment and real-time programming
  • Internal data logger, measured values can be read out in open format via USB
  • Unit self-test for comprehensive status analysis
  • Access port with silicone plug, 50 mm, left
  • Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
  • 4 castors, two with brakes
  • Computer interface: Ethernet
  • Adjustable ramp function
  • Integrated chart recorder
  • Real-time clock
  • 1 stainless steel rack
  • Inner chamber made of stainless steel
  • CFC-free refrigerant R-452A
  • Cooling with compressor cooling unit
  • Temperature range: -40 °C to 180 °C
  • APT.lineâ„¢ preheating chamber technology
  • Programmable condensation protection for test material
  • Heated viewing window with LED interior lighting
  • BINDER Multi Management Software APT-COMâ„¢ Basic Edition
  • Troubleshooting system with visual and audible alarms
  • Intuitive touchscreen controller with time-segment and real-time programming
  • Internal data logger, measured values can be read out in open format via USB
  • Unit self-test for comprehensive status analysis
  • Access port with silicone plug, 50 mm, left
  • Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
  • 4 castors, two with brakes
  • Computer interface: Ethernet
  • Adjustable ramp function
  • Integrated chart recorder
  • Real-time clock
  • 1 stainless steel rack
  • Inner chamber made of stainless steel
  • CFC-free refrigerant R-452A
  • Cooling with compressor cooling unit
  • Temperature range: -40 °C to 180 °C
  • APT.lineâ„¢ preheating chamber technology
  • Programmable condensation protection for test material
  • Heated viewing window with LED interior lighting
  • BINDER Multi Management Software APT-COMâ„¢ Basic Edition
  • Troubleshooting system with visual and audible alarms
  • Intuitive touchscreen controller with time-segment and real-time programming
  • Internal data logger, measured values can be read out in open format via USB
  • Unit self-test for comprehensive status analysis
  • Access port with silicone plug, 50 mm, left
  • Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
  • 4 castors, two with brakes
  • Computer interface: Ethernet
  • Adjustable ramp function
  • Integrated chart recorder
  • Real-time clock
  • 1 stainless steel rack
  • Inner chamber made of stainless steel
  • CFC-free refrigerant R-452A
  • Cooling with compressor cooling unit

Dynamic climate chamber MKFT 240

Multi Management Software APT-COMâ„¢

Key Industries

  • Education & Academics
  • Food & Beverage
  • Pharmaceutical
  • Service

Brand

Binder

With 22,000 series production machines supplied each year globally, family company BINDER is now one of the leading experts on environmental simulation chambers. For over 30 years at our German site in Tuttlingen, we have developed and produced premium products which combine superior technology, first-class advice, and exemplary service. These three factors are symbolized by the three red triangles that make up our logo – and our customers appreciate the benefits every day through the outstanding results of their work.
