A&D – Sine-Wave Vibro Viscometers – SV Series
Newly developed Tuning-fork Vibration method* promises you high accuracy and a wide measurement range without replacing the sensor plates!! (* Patent approved)
Viscometry Revolution!
Sine-wave Vibro Viscometer SV series measures viscosity by detecting the driving electric current necessary to resonate the two sensor plates at a constant frequency of 30Hz and amplitude of less than 1mm.
These viscometers easily measure the state transition from sol to gel, as there is no need to change sensors during measurement. Measurement intervals can be set freely allowing for continuous 24-hour measurement or measurement of any long-term viscosity change.
Technical Specifications
| SV-10 | SV-100 | |
|---|---|---|
| Viscosity Measurement Range | 0.3mPa·s – 10Pa·s (0.3 – 10,000mPa·s) | 1 – 100Pa·s (1,000 – 100,000mPa·s) |
| Viscosity Measurement Unit | mPa·s , Pa·s , cP , P | Pa·s , P |
| Accuracy | 1% of repeatability ( S.D. , 20 – 30°C , no condensation ) | 1% of repeatability ( S.D. , 20 – 30°C , no condensation ) |
| Operating temperature | 10 – 40°C (50 – 104°F) | 10 – 40°C (50 – 104°F) |
| Temperature measurement | 0 – 160°C /0.1°C ( 32 – 320°F/0.1°F ) | 0 – 160°C /0.1°C ( 32 – 320°F/0.1°F ) |
Key Features
SV Series
- Vibration frequency : 30 Hz
- Vacuum fluorescent display (VFD)
- Interface RS-232C
- Free WinCT-Viscosity
- Measurement of non-newtonian
SV Tuning Fork Viscometer
