AMADA – Advanced Glovebox Welding System – AX5000
AMADA WELD TECH’s AX5000 Glovebox is a rugged, tight, Windows® controlled atmospheric enclosure. It provides a safe, easy-to-access, easy-to-use system optimized for hermetic sealing applications as seen in electronic component packaging manufacturing.
Built in the USA, constructed of Type 304 internally polished stainless steel, the AX5000’s sturdy tubular frame provides solid support for automation and motion requirements. The atmospheric enclosure features an easily-removed safety glass window equipped with glove ports that have built-in armrests and butyl gloves. The AX5000 conforms to NASA-STD-3000 ergonomic standards, allowing comfortable use for a broad range of body types.
- Fully computerized operation
- Historical and real time graphical display
- Independent vacuum pumping systems on all ovens and antechambers
- Integrated moisture, oxygen, argon, and helium monitoring
- Configurable modular design
Technical Specification
| Leak Rate (at 2,5 mbar) | < 1.0 SCFH (0.3m3/h) | |
| Enclosure Size (W x D Floor / D top x H) | 1219 x 965 mm / 736 x 914 mm (48 x 39 in / 29 x 36 in) – 2 Glove Ports 1423 x 965 mm / 736 x 914 mm (56 x 39 in / 29 x 36 in) – 4 Glove Ports | |
|---|---|---|
| Antechamber and Oven Sizes (L x W x H) | 465 x 290 x 265 mm (18.5 x 11.5 x 10.5 in) – Stainless Steel 686 x 290 x 265 mm (27 x 11.5 x 10.5 in) – Stainless Steel | |
| Antechamber Controls | Computer: Backfill | |
| Oven Controls | Computer: Temperature, Vacuum, Backfill | |
| Antechamber & Oven Interlocks | Yes | |
| Antechamber & Automated Sliding Inner Door | Yes | |
| Antechamber and Oven Door Loading Options | Front, Rear, End | |
| Oven Heating Configuration | Heated Walls | |
| Heated Shelves | Heated Shelves | |
| Weight | Varies with selected options | |
| For further details, please refer to enclosed brochure. | ||
Available Models
| AX5000 – 48 | AX5000 – 56 | ||
|---|---|---|---|
| Dimensions (L x W x H) | 39 in x 48 in x 36 in (991 mm x 1219 mm x 915 mm) | 39 in x 56 in x 36 in (991 mm x 1423 mm x 915 mm) | |
| Number of glove ports | 2 | 4 | |
| Weight | Will vary with selected options | Will vary with selected options | |
| For further details, please refer to enclosed brochure. | |||
Key Features
AX5000
- Historical and real time graphical display of operating parameters, atmospheric conditions, status, data acquisition and oven bakeout batch reports
- Independent vacuum pumping systems dedicated to automatically and completely evacuating designated chambers
- Wide variety of vacuum oven configurations with exclusive closed-loop computer control and monitoring of each oven surface including heated shelves, ensures temperature stability
- Automatic push button inner and outer doors on ovens and antechambers
- Fully-integrated electronic gas pressure control system with userselectable set points and oil-less check valve
- Integrated moisture, oxygen and helium gas analyzers with real-time environmental control. Set points can be selected to trigger alarms or inhibit processes. Digital output provided for interface to process equipment
Key Industries
- Semiconductor, Solar & Electronics
